Name: BTF Fabrication Long Travel Suspension for Tacoma (2005-2015)
Brand: BTF Fabrication
Price: 3349.99 USD
Availability: InStock

BTF Fabrication Long Travel Suspension for Tacoma (2005-2015)

$3,349.99

Shipping calculated at checkout.

Select Finish

Raw; No Powdercoat

Gunmetal Powdercoat

Select Drivetrain

2WD; No Axles Needed

4WD; Include CV Axles

Select UCA Choice

Non-Adjustable w/ Poly Bushings

Adjustable w/ Heim Joints

In stock, ready to ship
Backordered, shipping soon

Transform suspension capability and off-road performance with this long travel suspension kit designed for aggressive trail use, rock crawling, and high-speed desert driving. Featuring increased track width, forward wheel positioning, and heavy-duty uniball construction, this system delivers exceptional wheel travel, durability, and alignment flexibility for serious off-road builds.

Important notes

• Lead time: Built to order with an estimated 8 to 12 week lead time depending on selected options and material availability
• Sales policy: All sales are final once the order is placed
• Fitment: Designed for 6 lug trucks only
• Options: Adjustable upper arms with FK heims and custom coilovers available as upgrades

Features

• Track width: Adds approximately 4.5 inches per side for improved stability and suspension travel
• Clearance: Moves suspension forward about 1 inch for additional firewall and oversized tire clearance
• Strength: Upper and lower ball joints replaced with 1.25 inch and 1 inch FK uniballs for maximum durability
• Articulation: Polyurethane bushings improve suspension movement and reduce deflection
• Alignment: Optional heims provide additional adjustability for performance tuning
• Steering: Tie rod extensions help maintain proper steering geometry with widened suspension
• Brake performance: Extended steel braided brake lines replace factory hard and soft sections
• Construction: Boxed control arms built to withstand demanding off-road conditions

Specifications

• Width increase: 4.5 inches per side
• Forward offset: Approximately 1 inch
• Maximum wheel travel: Up to 14 inches usable travel
• Upper uniball size: 1.25 inches
• Lower uniball size: 1 inch
• Axles: Custom heat treated 300M CV axle shafts with rebuilt OEM joints for 4WD kits
• Finish options: Raw or gunmetal grey powder coat

Included in the box

• Control arms: Boxed upper and lower control arms with polyurethane bushings
• Steering: Tie rod extensions
• Brake lines: Extended steel braided brake lines
• Adapters: Spindle to uniball adapters
• Brackets: Custom coilover top brackets
• Axles: Assembled custom CV axles included with 4WD kits
